Mini Tractor loader Liugong CLG816 For sale

FOB Reference Price:Get Latest Price
US $29,800-30,000 / Unit | 1 Unit/Units (Min. Order)
Supply Ability:
200 Unit/Units per Month
Port:
SHANGHAI
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Brand Name:
LiuGong
Model Number:
CLG820C
Place of Origin:
Guangxi, China (Mainland)
Type:
Front Loader
Moving Type:
Wheel Loader
Dimension(Long * Breadth * High):
6125x1940x2853 mm
Rated Load:
2ton
Certification:
ISO9001
Warranty:
1YEAR
After-sales Service Provided:
Engineers available to service machinery overseas
Packaging & Delivery
Packaging Details
NUDE PACKING
Delivery Time
10 DAYS

Mini Tractor loader Liugong CLG816 For sale

Features:



Built for Efficiency



Turbo air filter removes over 90% of dust and impurities, reducing  engine wear and fuel consumption extending engine service life and improving engine efficiency.



Radiator fan is directly engine driven and provides strong  efficient cooling.



38 degree angle of articulation for working in tight spaces.



Low fuel consumption engine that doesn't sacrifice any power.



Very low cycle time of 8.6 second, great for efficient  for smooth strong gear changes.



Meets EU stage IIIA/EPA tier 3 emission requirements.



 Easy to Maintain



Hydraulic system easily checked after removing front cover.



Easy engine access, convenient placement of key parts and fluid refill points.



 Always Reliable



Power cut-off function prevents damage to drive components.



Double sealed O-rings used in Hydraulic system.



Stress analysis tested to strengthen weak points.





Full Parameters:



Model

820C Wheel Loader

Bucker performance

1.0 m3

Operating weight

6,400 kg

Engine

emission regulation

Tier 2 / Stage II

make

YT4B4-24

gross power

65 kW (87 hp) @ 2,400 rpm

net power

60 kW (80 hp) @ 2,400 rpm

peak torque

305 N·m @ 1,600 rpm

displacement

9.7L

number of cylinders

4

aspiration

natural

Transmission

Transmission Type

counter shaft-type  power shift

Torque Converter

3 element-single stage,single phase

Maximum Travl Speed.fwd

25km/h

Maximum Travl Speed.rev

25km/h

number of Speed.fwd

2

number of Speed.rev

2

Brakes

Service Breake Type

caliper dry disc

Service Breake Actuation

 hydraulic

Parking Brake Type

shoe/drum

Parking Brake Actuation

mechanical

Hydraulic system

Main pump Type

gear

Main Relief Pressure

18Mpa

Raise

5.2 s

Dump Time

1.2s

Float Down Time

3s

Fastest Total Cycel Time

9.40 s

Loader arm performance

Tipping load-straight

4,997 kg

Tipping load-Full Turn

4,487 kg

Bucket Breakout Force

56 kN

Maximum Dump Angle at Full Height

45±1 °

Dump Clearance at full height discharge

2,856 mm

Dump reach at full height discharge

769 mm

Maximum hinge pin height

3,608 mm

Maximum Digging depth,Bucket level

23 mm

Bucket rollback at ground level

45 °

Bucket rollback at carry

49 °

Bucket rollback at maximum height

61 °

Dimensions

Length with bucket down

6,125 mm

width over tires

1904mm

wheelbase

2,310 mm

wheel Tread

1520mm

Ground Clearance

285mm

Turn Angle,Either Side

38°

Rear Angle of Departure

28.5°

Turning Radius,Outside of Tire

4,347 mm

Turning Radius,Center of Tire

4,119 mm

Turning Radius,Bucket Carry

4,979 mm

Service Capacities

FuelTank

95L

Engine Oil

16L

Cooling System

21L

Hydraulic Reservoir

78L

Transmission and Torque Converter

20L

Axles,each

12 L


Photos
